LongGene
Leading Pettier Elements from MARLOW,ensure long life of 1,000,000 thermal cycles and fast ramping rate up to 6℃/S。
T-opticalTM technology,reduce background noise,improve fluorescence signal sensitlvity and singnal to noise ratio.
The angle of display could be adjusted to the best view.
Simultaneous detection of wells,not in sequence.
Users could view qPCR process and run PCR protocol through self-contained 10"TFT LCD and touch screen.
Innovative SSLPTM CCD imaging technology for qPCR,avoiding more moving parts problems like overheat,wear and off center.Not optical fiber based, avoiding break and block by dust.
Long life LED lamps to excite fluorescence ,no need for replacement in the future.
Sample wells with temperature gradient function, convenient to optimize PCR conditions
Equipped with LongGene's "Optimun qPCR Design& Analysis Software" for remote operation of instruments and analysis of results.
The drawer design of sample block,makes it easier to plck and place PCR tubes and plates
LongGene's "Optimun qPCR Design& Analysis Software" could be upgraded for free.
Leading Pettier Elements from MARLOW,ensure long life of 1,000,000 thermal cycles and fast ramping rate up to 6℃/S。
T-opticalTM technology,reduce background noise,improve fluorescence signal sensitlvity and singnal to noise ratio.
The angle of display could be adjusted to the best view.
Simultaneous detection of wells,not in sequence.
Users could view qPCR process and run PCR protocol through self-contained 10"TFT LCD and touch screen.
Innovative SSLPTM CCD imaging technology for qPCR,avoiding more moving parts problems like overheat,wear and off center.Not optical fiber based, avoiding break and block by dust.
Long life LED lamps to excite fluorescence ,no need for replacement in the future.
Sample wells with temperature gradient function, convenient to optimize PCR conditions
Equipped with LongGene's "Optimun qPCR Design& Analysis Software" for remote operation of instruments and analysis of results.
The drawer design of sample block,makes it easier to plck and place PCR tubes and plates
LongGene's "Optimun qPCR Design& Analysis Software" could be upgraded for free.
Model | Q 2000B/Q2000BR(for research only) |
Instrument Performance | |
Sample Block Capacity | 96wells*0.1ml |
Reaction Volume | 10-50ul |
Tubes Option | White PCR tubes or strips or 96well PCR piate,with optical flat cap |
Heating&Cooling Technology | Peltier technonlong allow1,000,000 thermal cycles |
Control Methods | Operated via PC or self-contaiend touch screen on instrument |
Language | Englisn |
Communications | USB2.0 or LAN |
Display | 10"Colcr TFT LCD and Touch Screen,view angle adjustable |
Max.Number of programs | Max.15,000 programs onboard,unlimited storage of pretocols with USB flash drive |
Certified | CE-IVD/Non CE-IVD |
Temperature | |
Block Temp.Range | 0~105℃ |
Max.Heating Rate | 6℃/sec |
Max.Cooling Rate | 5℃/sec |
Temp.Uniformity | ≤±0.2℃ (at 90℃) |
Temp.Accuracy | ≤±0.1℃ (at 90℃) |
Display Resolution | 0.1℃ |
Heat Lid Temp.Rage | 30℃~120℃ |
Gradient Range | 30℃-100℃ |
Temp.differential Range | 1℃-42℃ |
Fluorescence Detection | |
Excitation | Long life LED lanps |
Detection | CCDs |
Dynamic Range | 1-1010 |
Sensitivity | ≥1 copy |
Calibrated Dyes at installation | F1:FAM/SYBR Green F2:VIC/HEX/JOE/CY3/TET*(★ Reserved) F3:ROX/ TEXAS-RED/TAMRA*(★Reserved) F4:CY5/Quasar670 |
Fluorescence Excitation Range | 300-800nm |
Fluorescence Detection Range | 500-800nm |
Date Export Formats | TXT,PDF,WORD,Excel |
Other Features | |
AC Power Supply | 100-240V,50-60Hz |
Consupmtion | 600W |
Net Weight | 13kg |
Dimension(L*W*H) | 334*280*365mm |
Computer Operating Systems | Windows10、Windows7、WindowsXP |
